High Quality Preformed Dead End Guy Grip for ADSS Cable Strain Tension Cable Clamp
May 31, 2024
Product Description
Material:
Dead-ends: High-tensile galvanized steel or alloy steel.
Application:
Suited for the full tensile of insulated conductors on transmission and distribution lines.
Technical Sheet:
| Model | Section area (mm²) |
Overall diameter (mm) | Clamp length (mm) |
Clamp weight (kg) |
| NL-35/JY | 35 | 14.80 | 900 | 0.8 |
| NL-50/JY | 50 | 16.10 | 980 | 1.1 |
| NL-150/JY | 150 | 22.60 | 1020 | 1.8 |
| NL-185/JY | 185 | 24.20 | 1020 | 2.2 |
| NL-300/JY | 300 | 28.60 | 1020 | 3.0 |
